LED601 | BFM Louvers

Single Bank

Technical Data

Material: Aluminium 6063-T5
Pitch: 70 mm
Depth: 140 mm
Mullion System: Hidden Mullion
Airflow Class: 2
Airflow Rating: Very Good
Rain Defence Rating: Good
Pressure Drop: 14 PA 3.5 m/s
Free Area: 42.4%
